Guide for Authors

print('Welcome to "The Debugging Book"!')
Welcome to "The Debugging Book"!

This notebook compiles the most important conventions for all chapters (notebooks) of "The Debugging Book".

Organization of this Book

Chapters as Notebooks

Each chapter comes in its own Jupyter notebook. A single notebook (= a chapter) should cover the material (text and code, possibly slides) for a 90-minute lecture.

A chapter notebook should be named Topic.ipynb, where Topic is the topic. Topic must be usable as a Python module and should characterize the main contribution. If the main contribution of your chapter is a class FooDebugger, for instance, then your topic (and notebook name) should be FooDebugger, such that users can state

from FooDebugger import FooDebugger

Since class and module names should start with uppercase letters, all non-notebook files and folders start with lowercase letters. this may make it easier to differentiate them. The special notebook index.ipynb gets converted into the home pages index.html (on fuzzingbook.org) and README.md (on GitHub).

Notebooks are stored in the notebooks folder.

DebuggingBook and FuzzingBook

This project shares some infrastructure (and even chapters) with "The Fuzzing Book", established through symbolic links. Your file organization should be such that debuggingbook and fuzzingbook are checked out in the same folder; otherwise, sharing infrastructure will not work

<some folder>
|- fuzzingbook
|- debuggingbook (this project folder)

To check whether the organization fits, check whether the debuggingbook Makefile properly points to ../fuzzingbook/Makefile - that is, the fuzzingbook Makefile. If you can properly open the (shared) Makefile in both projects, things are set up properly.

Output Formats

The notebooks by themselves can be used by instructors and students to toy around with. They can edit code (and text) as they like and even run them as a slide show.

The notebook can be exported to multiple (non-interactive) formats:

  • HTML – for placing this material online.
  • PDF – for printing
  • Python – for coding
  • Slides – for presenting

The included Makefile can generate all of these automatically (and a few more).

At this point, we mostly focus on HTML and Python, as we want to get these out quickly; but you should also occasionally ensure that your notebooks can (still) be exported into PDF. Other formats (Word, Markdown) are experimental.

Sites

All sources for the book end up on the Github project page. This holds the sources (notebooks), utilities (Makefiles), as well as an issue tracker.

The derived material for the book ends up in the docs/ folder, from where it is eventually pushed to the debuggingbook website. This site allows to read the chapters online, can launch Jupyter notebooks using the binder service, and provides access to code and slide formats. Use make publish to create and update the site.

The Book PDF

The book PDF is compiled automatically from the individual notebooks. Each notebook becomes a chapter; references are compiled in the final chapter. Use make book to create the book.

Creating and Building

Tools you will need

To work on the notebook files, you need the following:

  1. Jupyter notebook. The easiest way to install this is via the Anaconda distribution.

  2. Once you have the Jupyter notebook installed, you can start editing and coding right away by starting jupyter notebook (or jupyter lab) in the topmost project folder.

  3. If (like me) you don't like the Jupyter Notebook interface, I recommend Jupyter Lab, the designated successor to Jupyter Notebook. Invoke it as jupyter lab. It comes with a much more modern interface, but misses autocompletion and a couple of extensions. I am running it as a Desktop application which gets rid of all the browser toolbars. On the Mac, there is also the Pineapple app, which integrates a nice editor with a local server. This is easy to use, but misses a few features; also, it hasn't seen updates since 2015.

  4. To create the entire book (with citations, references, and all), you also need the ipybublish package. This allows you to create the HTML files, merge multiple chapters into a single PDF or HTML file, create slides, and more. The Makefile provides the essential tools for creation.

Version Control

We use git in a single strand of revisions. Feel free branch for features, but eventually merge back into the main "master" branch. Sync early; sync often. Only push if everything ("make all") builds and passes.

The Github repo thus will typically reflect work in progress. If you reach a stable milestone, you can push things on the fuzzingbook.org web site, using make publish.

nbdime

The nbdime package gives you tools such as nbdiff (and even better, nbdiff-web) to compare notebooks against each other; this ensures that cell contents are compared rather than the binary format.

nbdime config-git --enable integrates nbdime with git such that git diff runs the above tools; merging should also be notebook-specific.

nbstripout

Notebooks in version control should not contain output cells, as these tend to change a lot. (Hey, we're talking random output generation here!) To have output cells automatically stripped during commit, install the nbstripout package and use

nbstripout --install

to set it up as a git filter. The notebooks/ folder comes with a .gitattributes file already set up for nbstripout, so you should be all set.

Note that published notebooks (in short, anything under the docs/ tree should have their output cells included, such that users can download and edit notebooks with pre-rendered output. This folder contains a .gitattributes file that should explicitly disable nbstripout, but it can't hurt to check.

As an example, the following cell

  1. should have its output included in the HTML version of this guide;
  2. should not have its output included in the git repo (notebooks/);
  3. should have its output included in downloadable and editable notebooks (docs/notebooks/ and docs/beta/notebooks/).
import random
random.random()
0.9225046251257348

Inkscape and GraphViz

Creating derived files uses Inkscape and Graphviz – through its Python wrapper – to process SVG images. These tools are not automatically installed, but are available on pip, brew and apt-get for all major distributions.

LaTeX Fonts

By default, creating PDF uses XeLaTeX with a couple of special fonts, which you can find in the fonts/ folder; install these fonts system-wide to make them accessible to XeLaTeX.

You can also run make LATEX=pdflatex to use pdflatex and standard LaTeX fonts instead.

Creating Derived Formats (HTML, PDF, code, ...)

The Makefile provides rules for all targets. Type make help for instructions.

The Makefile should work with GNU make and a standard Jupyter Notebook installation. To create the multi-chapter book and BibTeX citation support, you need to install the iPyPublish package (which includes the nbpublish command).

Creating a New Chapter

To create a new chapter for the book,

  1. Set up a new .ipynb notebook file as copy of Template.ipynb.
  2. Include it in the CHAPTERS list in the Makefile.
  3. Add it to the git repository.

Teaching a Topic

Each chapter should be devoted to a central concept and a small set of lessons to be learned. I recommend the following structure:

  • Introduce the problem ("We want to parse inputs")
  • Illustrate it with some code examples ("Here's some input I'd like to parse")
  • Develop a first (possibly quick and dirty) solution ("A PEG parser is short and often does the job"_
  • Show that it works and how it works ("Here's a neat derivation tree. Look how we can use this to mutate and combine expressions!")
  • Develop a second, more elaborated solution, which should then become the main contribution. ("Here's a general LR(1) parser that does not require a special grammar format. (You can skip it if you're not interested)")
  • Offload non-essential extensions to later sections or to exercises. ("Implement a universal parser, using the Dragon Book")

The key idea is that readers should be able to grasp the essentials of the problem and the solution in the beginning of the chapter, and get further into details as they progress through it. Make it easy for readers to be drawn in, providing insights of value quickly. If they are interested to understand how things work, they will get deeper into the topic. If they just want to use the technique (because they may be more interested in later chapters), having them read only the first few examples should be fine for them, too.

Whatever you introduce should be motivated first, and illustrated after. Motivate the code you'll be writing, and use plenty of examples to show what the code just introduced is doing. Remember that readers should have fun interacting with your code and your examples. Show and tell again and again and again.

Special Sections

Quizzes

You can have quizzes as part of the notebook. These are created using the quiz() function. Its arguments are

  • The question
  • A list of options
  • The correct answer(s) - either
    • the single number of the one single correct answer (starting with 1)
    • a list of numbers of correct answers (multiple choices)

To make the answer less obvious, you can specify it as a string containing an arithmetic expression evaluating to the desired number(s). The expression will remain in the code (and possibly be shown as hint in the quiz).

from bookutils import quiz
# A single-choice quiz
quiz("The color of the sky is",
     [
         "blue",
         "red",
         "black"
     ], '5 - 4')

Quiz

The color of the sky is




# A multiple-choice quiz
quiz("What is this book?",
     [
         "Novel",
         "Friendly",
         "Useful"
     ], '[5 - 4, 1 + 1, 27 / 9]')

Quiz

What is this book?




Cells that contain only the quiz() call will not be rendered (but the quiz will).

Synopsis

Each chapter should have a section named "Synopsis" at the very end:

## Synopsis

This is the text of the synopsis.

This section is evaluated at the very end of the notebook. It should summarize the most important functionality (classes, methods, etc.) together with examples. In the derived HTML and PDF files, it is rendered at the beginning, such that it can serve as a quick reference

Excursions

There may be longer stretches of text (and code!) that are too special, too boring, or too repetitve to read. You can mark such stretches as "Excursions" by enclosing them in MarkDown cells that state:

#### Excursion: TITLE

and

#### End of Excursion

Stretches between these two markers get special treatment when rendering:

  • In the resulting HTML output, these blocks are set up such that they are shown on demand only.
  • In printed (PDF) versions, they will be replaced by a pointer to the online version.
  • In the resulting slides, they will be omitted right away.

Here is an example of an excursion:

Fine points on Excursion Cells

Note that the Excursion and End of Excursion cells must be separate cells; they cannot be merged with others.

Ignored Code

If a code cell starts with

# ignore

then the code will not show up in rendered input. Its output will, however. This is useful for cells that create drawings, for instance - the focus should be on the result, not the code.

This also applies to cells that start with a call to display() or quiz().

Ignored Cells

You can have any cell not show up at all (including its output) in any rendered input by adding the following meta-data to the cell:

{
    "ipub": {
        "ignore": true
}

Documentation Assertions

If a code cell starts with

# docassert

then the code will not show up in rendered input (like # ignore), but also not in exported code. This is useful for inserting assertions that encode assumptions made in the (following) documentation. Having this assertion fail means that the documentation no longer applies.

Since the documentation is not part of exported code, and since code may behave differently in standalone Python, these assertions are not exported.

Coding

Set up

The first code block in each notebook should be

import bookutils

This sets up stuff such that notebooks can import each other's code (see below). This import statement is removed in the exported Python code, as the .py files would import each other directly.

Importing bookutils also sets a fixed seed for random number generation. This way, whenever you execute a notebook from scratch (restarting the kernel), you get the exact same results; these results will also end up in the derived HTML and PDF files. (If you run a notebook or a cell for the second time, you will get more random results.)

Coding Style and Consistency

Here's a few rules regarding coding style.

Use Python 3

We use Python 3 (specifically, Python 3.6) for all code. As of 2020, there is no need anymore to include compatibility hacks for Python 2.

Follow Python Coding Conventions

We use standard Python coding conventions according to PEP 8.

Your code must pass the pycodestyle style checks which you get by invoking make style. A very easy way to meet this goal is to invoke make reformat, which reformats all code accordingly. The code prettify notebook extension also allows you to automatically make your code (mostly) adhere to PEP 8.

One Cell per Definition

Use one cell for each definition or example. During importing, this makes it easier to decide which cells to import (see below).

Identifiers

In the book, this is how we denote variables, functions() and methods(), Classes, Notebooks, variables_and_constants, EXPORTED_CONSTANTS, files, folders/, and <grammar-elements>.

Quotes

If you have the choice between quoting styles, prefer

  • double quotes ("strings") around strings that are used for interpolation or that are natural language messages, and
  • single quotes ('characters') for single characters and formal language symbols that a end user would not see.

Static Type Checking

Use type annotations for all function definitions.

Documentation

Use documentation strings for all public classes and methods.

Read More

Beyond simple syntactical things, here's a very nice guide to get you started writing "pythonic" code.

Importing Code from Notebooks

To import the code of individual notebooks, you can import directly from .ipynb notebook files.

from DeltaDebugger import DeltaDebugger
def fun(s: str) -> None:
    assert 'a' not in s

with DeltaDebugger() as dd:
    fun("abc")
dd
fun(s='a')

Important: When importing a notebook, the module loader will only load cells that start with

  • a function definition (def)
  • a class definition (class)
  • a variable definition if all uppercase (ABC = 123)
  • import and from statements

All other cells are ignored to avoid recomputation of notebooks and clutter of print() output.

Exported Python code will import from the respective .py file instead. The exported Python code is set up such that only the above items will be imported.

If importing a module prints out something (or has other side effects), that is an error. Use make check-imports to check whether your modules import without output.

Import modules only as you need them, such that you can motivate them well in the text.

Imports and Dependencies

Try to depend on as few other notebooks as possible. This will not only ease construction and reconstruction of the code, but also reduce requirements for readers, giving then more flexibility in navigating through the book.

When you import a notebook, this will show up as a dependency in the Sitemap. If the imported module is not critical for understanding, and thus should not appear as a dependency in the sitemap, mark the import as "minor dependency" as follows:

from Intro_Debugging import remove_html_markup  # minor dependency

Design and Architecture

Stick to simple functions and data types. We want our readers to focus on functionality, not Python. You are encouraged to write in a "pythonic" style, making use of elegant Python features such as list comprehensions, sets, and more; however, if you do so, be sure to explain the code such that readers familiar with, say, C or Java can still understand things.

Incomplete Examples

When introducing examples for students to complete, use the ellipsis ... to indicate where students should add code, as in here:

def student_example() -> None:
    x = some_computation()
    # Now, do something with x
    ...

The ellipsis is legal code in Python 3. (Actually, it is an Ellipsis object.)

Introducing Classes

Defining classes can be a bit tricky, since all of a class must fit into a single cell. This defeats the incremental style preferred for notebooks. By defining a class as a subclass of itself, though, you can avoid this problem.

Here's an example. We introduce a class Foo:

class Foo:
    def __init__(self) -> None:
        pass

    def bar(self) -> None:
        pass

Now we could discuss what __init__() and bar() do, or give an example of how to use them:

f = Foo()
f.bar()

We now can introduce a new Foo method by subclassing from Foo into a class which is also called Foo:

class Foo(Foo):
    def baz(self) -> None:
        pass

This is the same as if we had subclassed Foo into Foo_1 with Foo then becoming an alias for Foo_1. The original Foo class is overshadowed by the new one:

new_f = Foo()
new_f.baz()

Note, though, that existing objects keep their original class:

from ExpectError import ExpectError
with ExpectError(AttributeError):
    f.baz()
Traceback (most recent call last):
  File "<ipython-input-1-12b6020f98db>", line 2, in <module>
    f.baz()  # type: ignore
AttributeError: 'Foo' object has no attribute 'baz' (expected)

Helpers

There's a couple of notebooks with helpful functions, including Timer, ExpectError and ExpectTimeout. Also check out the Tracer class.

Quality Assurance

In your code, make use of plenty of assertions that allow to catch errors quickly. These assertions also help your readers understand the code.

Issue Tracker

The Github project page allows to enter and track issues.

Writing Text

Text blocks use Markdown syntax. Here is a handy guide.

Sections

Any chapter notebook must begin with # TITLE, and sections and subsections should then follow by ## SECTION and ### SUBSECTION.

Sections should start with their own block, to facilitate cross-referencing.

Highlighting

Use

  • emphasis (_emphasis_) for highlighting,
  • emphasis (*emphasis*) for highlighting terms that will go into the index,
  • backticks for code and other verbatim elements.

Hyphens and Dashes

Use "–" for em-dashes, "-" for hyphens, and "$-$" for minus.

Quotes

Use standard typewriter quotes ("quoted string") for quoted text. The PDF version will automatically convert these to "smart" (e.g. left and right) quotes.

Lists and Enumerations

You can use bulleted lists:

  • Item A
  • Item B

and enumerations:

  1. item 1
  2. item 2

For description lists, use a combination of bulleted lists and highlights:

  • PDF is great for reading offline
  • HTML is great for reading online

Math

LaTeX math formatting works, too.

$x = \sum_{n = 1}^{\infty}\frac{1}{n}$ gets you $x = \sum_{n = 1}^{\infty}\frac{1}{n}$.

Inline Code

Python code normally goes into its own cells, but you can also have it in the text:

s = "Python syntax highlighting"
print(s)

Images

To insert images, use Markdown syntax ![Word cloud](PICS/wordcloud.png){width=100%} inserts a picture from the PICS folder.

Word cloud{width=100%}

All pictures go to PICS/, both in source as well as derived formats; both are stored in git, too. (Not all of us have all tools to recreate diagrams, etc.)

Footnotes

Markdown supports footnotes, as in 1. These are rendered as footnotes in HTML and PDF, but not within Jupyter; hence, readers may find them confusing. So far, the book makes no use of footnotes, and uses parenthesized text instead.


  1. Test, Link.

Floating Elements and References

\todo[inline]{I haven't gotten this to work yet -- AZ}

To produce floating elements in LaTeX and PDF, edit the metadata of the cell which contains it. (In the Jupyter Notebook Toolbar go to View -> Cell Toolbar -> Edit Metadata and a button will appear above each cell.) This allows you to control placement and create labels.

Floating Figures

Edit metadata as follows:

{
"ipub": {
  "figure": {
    "caption": "Figure caption.",
    "label": "fig:flabel",
    "placement": "H",
    "height":0.4,
    "widefigure": false,
    }
  }
}
  • all tags are optional
  • height/width correspond to the fraction of the page height/width, only one should be used (aspect ratio will be maintained automatically)
  • placement is optional and constitutes using a placement arguments for the figure (e.g. \begin{figure}[H]). See Positioning_images_and_tables.
  • widefigure is optional and constitutes expanding the figure to the page width (i.e. \begin{figure*}) (placement arguments will then be ignored)

Floating Tables

For tables (e.g. those output by pandas), enter in cell metadata:

{
"ipub": {
     "table": {
        "caption": "Table caption.",
        "label": "tbl:tlabel",
        "placement": "H",
            "alternate": "gray!20"
      }
   }
}

Floating Equations

For equations (e.g. those output by sympy), enter in cell metadata:

{
  "ipub": {
      "equation": {
        "environment": "equation",
        "label": "eqn:elabel"
      }
  }
}
  • environment is optional and can be 'none' or any of those available in amsmath; 'equation', 'align','multline','gather', or their * variants. Additionally, 'breqn' or 'breqn*' will select the experimental breqn environment to smart wrap long equations.
  • label is optional and will only be used if the equation is in an environment

References

To reference a floating object, use \cref, e.g. eq. 1

Cross-Referencing

Section References

  • To refer to sections in the same notebook, use the header name as anchor, e.g. [Code](#Code) gives you Code. For multi-word titles, replace spaces by hyphens (-), as in Using Notebooks as Modules.

  • To refer to cells (e.g. equations or figures), you can define a label as cell metadata. See Floating Elements and References for details.

  • To refer to other notebooks, use a Markdown cross-reference to the notebook file, e.g. the "Debugger" chapter. A special script will be run to take care of these links. Reference chapters by name, not by number.

Citations

To cite papers, cite in LaTeX style. The text

print(r"\cite{Purdom1972}")
\cite{Purdom1972}

is expanded to [Purdom et al, 1972], which in HTML and PDF should be a nice reference. The keys refer to BibTeX entries in fuzzingbook.bib.

  • LaTeX/PDF output will have a "References" section appended.
  • HTML output will link to the URL field from the BibTeX entry. Be sure it points to the DOI.

Todo's

  • To mark todo's, use \todo{Thing to be done}. \todo{Expand this}

Tables

Tables with fixed contents can be produced using Markdown syntax:

Tables Are Cool
Zebra 2 30
Gnu 20 400

If you want to produce tables from Python data, the PrettyTable package (included in the book) allows to produce tables with LaTeX-style formatting.

from bookutils import PrettyTable as pt
import numpy as np
data = np.array([[1, 2, 30], [2, 3, 400]])
pt.PrettyTable(data, [r"$\frac{a}{b}$", r"$b$",
                      r"$c$"], print_latex_longtable=False)
$\frac{a}{b}$$b$$c$
1230
23400

Plots and Data

It is possible to include plots in notebooks. Here is an example of plotting a function:

%matplotlib inline

import matplotlib.pyplot as plt

x = np.linspace(0, 3 * np.pi, 500)
plt.plot(x, np.sin(x ** 2))
plt.title('A simple chirp');
Text(0.5, 1.0, 'A simple chirp')

And here's an example of plotting data:

%matplotlib inline

import matplotlib.pyplot as plt
data = [25, 36, 57]
plt.plot(data)
plt.title('Increase in data');
Text(0.5, 1.0, 'Increase in data')

Plots are available in all derived versions (HTML, PDF, etc.) Plots with plotly are even nicer (and interactive, even in HTML), However, at this point, we cannot export them to PDF, so matplotlib it is.

Slides

You can set up the notebooks such that they also can be presented as slides. In the browser, select View -> Cell Toolbar -> Slideshow. You can then select a slide type for each cell:

  • New slide starts a new slide with the cell (typically, every ## SECTION in the chapter)
  • Sub-slide starts a new sub-slide which you navigate "down" to (anything in the section)
  • Fragment is a cell that gets revealed after a click (on the same slide)
  • Skip is skipped during the slide show (e.g. import statements; navigation guides)
  • Notes goes into presenter notes

To create slides, do make slides; to view them, change into the slides/ folder and open the created HTML files. (The reveal.js package has to be in the same folder as the slide to be presented.)

The ability to use slide shows is a compelling argument for teachers and instructors in our audience.

(Hint: In a slide presentation, type s to see presenter notes.)

Writing Tools

When you're editing in the browser, you may find these extensions helpful:

Jupyter Notebook

Jupyter Notebook Extensions is a collection of productivity-enhancing tools (including spellcheckers).

I found these extensions to be particularly useful:

  • Spell Checker (while you're editing)

  • Table of contents (for quick navigation)

  • Code prettify (to produce "nice" syntax)

  • Codefolding

  • Live Markdown Preview (while you're editing)

Jupyter Lab

Extensions for Jupyter Lab are much less varied and less supported, but things get better. I am running

Interaction

It is possible to include interactive elements in a notebook, as in the following example:

try:
    from ipywidgets import interact, interactive, fixed, interact_manual

    x = interact(fuzzer, char_start=(32, 128), char_range=(0, 96))
except ImportError:
    pass

Note that such elements will be present in the notebook versions only, but not in the HTML and PDF versions, so use them sparingly (if at all). To avoid errors during production of derived files, protect against ImportError exceptions as in the above example.

Read More

Here is some documentation on the tools we use:

  1. Markdown Cheatsheet - general introduction to Markdown

  2. iPyPublish - rich set of tools to create documents with citations and references

Alternative Tool Sets

We don't currently use these, but they are worth learning:

  1. Making Publication-Ready Python Notebooks - Another tool set on how to produce book chapters from notebooks

  2. Writing academic papers in plain text with Markdown and Jupyter notebook - Alternate ways on how to generate citations

  3. A Jupyter LaTeX template - How to define a LaTeX template

  4. Boost Your Jupyter Notebook Productivity - a collection of hints for debugging and profiling Jupyter notebooks

Creative Commons License The content of this project is licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License. The source code that is part of the content, as well as the source code used to format and display that content is licensed under the MIT License. Last change: 2021-05-18 11:29:44+02:00CiteImprint
